Thermtec Wild 635 L thermalcamera, 35 mm LRF lens

The ThermTec WILD 635L thermal imaging camera offers a highly sensitive 640x512 sensor (NETD ≤ 18 mK) and a laser range finder (LRF) with a range of up to 1,000 m. Thanks to LRF Boost technology, it combines AI and laser rangefinding to precisely detect multiple targets. It has an AMOLED display with 1024x768 pixels, a rechargeable battery system with up to 8 hours of operating time and a robust, IP67-certified housing. With 64 GB memory, 6 colour palettes and extensive image settings, the WILD 635L is ideal for demanding applications. Scope of delivery: Camera, 2 batteries, charger, USB-C cable, wrist strap, neck strap, storage bag.

Manufacturer: ThermTec

Model: WILD 635L

Objective lens Ø: 35 mm

Lens aperture: F0.9

Frame rate: 50 Hz

Pixel size: 12 µm

NETD value @300K (system performance): < 18 mK

Battery life: 8 hours

Resolution of the microbolometer: 640x512 pixels

Sensor type (sun-safe): VOx

Horizontal/vertical field of view: 12.5° x 10.0°

Field of view width at 100 m: 22.0 m

AMOLED display resolution: 1024 x 768 pixels

Optical magnification: 2x

Digital magnification (zoom): 1x - 4x stepless

Dioptre adjustment for spectacle wearers: Yes

Colour palettes: 6

Detection distance: 1800 m

Detection distance (deer): 600 m

Hotspot connection: Yes

AI rangefinder: Yes

AI object detection: Yes

Laser range finder (LRF): Yes

LRF range: 1,000 m

LRF accuracy: +/-1 m

LRF boost technology: Yes

Marking laser: No

Object alarm (via APP): Yes

Stadiametric rangefinder: No

Hot spot marking function: Yes

Picture-in-Picture (PIP): Yes

Recording function: Yes

Playback function: Yes

Manual lens focus: Yes

Internal memory: 64 GB

Protection class: IP67

Weight: 505 g

Dimensions (LxWxH): 190x69x77 mm

Operating temperature: -20°C to +50°C

Battery type: Li-ion

Charging voltage: 3.7 V

External power supply (USB): 5 V
